BGS-FW2308 1450KV 1kg Payload Fixed-Wing Motor for 8inch/9inch Drone

Product Number:FW2308

These long-shaft brushless motors include KV1450 and KV2600 variants with 12N14P slot-pole structure. Lightweight 47/48g units run on 2-4S LiPo, delivering steady 23A/28A max current for compact small fixed-wing aircraft.

Motor dimensions
28.8*40.5mm
Number of slots
12N14P
Copper wire grade
200℃
Shaft diameter
4mm
Motor weight
47g
Service life
＞1000h

Technical Specifications

AT2308 Basic Data
Motor Dimensions:28.8*40.5mm	Lead Wire Specification:AWG 100mm
Shaft Diameter:4mm	No-load Current (10V):0.8A
Maximum Continuous Power:87W	Weight (with Wire):47g
Phase-to-phase Internal Resistance:90m	Slot-pole Configuration:12N14P
Rated Operating Voltage (Lipo):2-4S	Maximum Current (180s):23A

Basic Data

MODEL	KV Value	Maximum power	Maximum current	Pull	Efficiency	Applicable blades	Number of batteries	Adapt to electric adjustment
BGS-FW2308	KV	W	A	g	g/W	/	S	A
	1450	867	9858	19.07	4.15	APC 8*6	4	30
	1450	1045	8827	22.42	4.24	APC 9*6	3	35
	2600	930	20690	26.89	3.25	APC 6*4	3	40

test data

Model	Accelerator	Voltage	Pulling Force	Torque	Current	Speed	Power	Efficiency	Motor temperature
BGS-FW2308 KV1450 APC 8*6	%	V	g	N.m	A	rpm	W	g/W	℃
	40%	11.32	4.21	47.47	5990.00	0.05	294.00	6.19	53
	45%	11.31	4.97	56.05	6347.00	0.06	333.00	5.93
	50%	11.29	5.78	65.13	6699.00	0.06	371.00	5.69
	55%	11.26	6.79	76.33	7108.00	0.07	419.00	5.48
	60%	11.24	7.95	89.12	7586.00	0.07	481.00	5.39
	65%	11.21	9.27	103.65	7978.00	0.08	554.00	5.34
	70%	11.18	10.57	117.97	8343.00	0.09	607.00	5.15
	75%	11.14	12.11	134.73	8709.00	0.10	666.00	4.94
	80%	11.09	13.98	154.89	9099.00	0.11	730.00	4.72
	90%	11.00	17.98	197.61	9737.00	0.13	843.00	4.27
	100%	10.97	19.07	209.07	9858.00	0.13	867.00	4.15
BGS-FW2308 KV1450 APC 9*6	40%	11.42	4.33	49.38	5272.00	0.05	328.00	6.64	79
	45%	11.40	5.22	59.34	5631.00	0.06	377.00	6.36
	50%	11.38	6.42	72.85	6054.00	0.07	445.00	6.11
	55%	11.35	7.68	86.97	6474.00	0.08	518.00	5.96
	60%	11.31	9.29	104.94	6904.00	0.09	596.00	5.68
	65%	11.27	10.95	123.44	7265.00	0.10	667.00	5.40
	70%	11.23	12.74	142.96	7604.00	0.11	742.00	5.19
	75%	11.19	14.48	161.78	7908.00	0.12	807.00	4.99
	80%	11.15	16.46	183.27	8173.00	0.13	873.00	4.76
	90%	11.04	20.83	229.72	8681.00	0.15	1007.00	4.38
	100%	11.00	22.42	246.35	8827.00	0.16	1045.00	4.24
BGS-FW2308 KV2600 APC 6*4	40%	11.20	9.08	101.56	14240.00	0.04	432.00	4.25	49
	45%	11.16	10.29	114.80	14981.00	0.05	475.00	4.14
	50%	11.12	11.62	129.07	15645.00	0.05	518.00	4.01
	55%	11.09	12.80	141.78	16198.00	0.06	557.00	3.93
	60%	11.06	14.02	154.91	16580.00	0.06	596.00	3.85
	65%	11.02	15.26	167.99	17230.00	0.07	632.00	3.76
	70%	10.99	16.46	180.71	17665.00	0.07	669.00	3.70
	75%	10.95	17.73	194.07	18147.00	0.07	704.00	3.63
	80%	10.90	19.73	214.93	18835.00	0.08	760.00	3.53
	90%	10.73	25.03	268.46	20249.00	0.09	892.00	3.32
	100%	10.65	26.89	286.24	20690.00	0.10	930.00	3.25
