88.5*32mm
36N48P
200℃
15mm
368g
＞1000h
| MODEL | KV Value | maximum power | Maximum current | pull | Efficiency | Propeller | Battery | ESC | |
| BGS-UA90 | KV | W | A | g | g/W | / | S | A | |
| 220 | 1354.20 | 61.00 | 8700 | 6.42 | UC3095L | 6 | / | ||
| 220 | 1327.56 | 59.80 | 8300 | 6.25 | UC2995L | 6 | / | ||
| 220 | 1329.78 | 59.90 | 8000 | 6.02 | UC2880L | 6 | / | ||
| 150 | 2832.72 | 63.80 | 11600 | 4.10 | UC2788L | 12 | / | ||
| 150 | 2357.64 | 53.10 | 11400 | 4.84 | UC2680L | 12 | / | ||
| 150 | 2197.80 | 49.50 | 1000 | 4.55 | UC2480L | 12 | / | ||
| 120 | 1514.04 | 34.10 | 8800 | 5.81 | UF2788L | 12 | / | ||
| 120 | 2082.36 | 46.90 | 10680 | 5.13 | UC2880L | 12 | / | ||
| 120 | 1975.80 | 44.50 | 10750 | 5.44 | UC2995L | 12 | / | ||
| 120 | 2197.80 | 49.50 | 11000 | 5.01 | UC3095L | 12 | / | ||
| 120 | 2243.01 | 48.55 | 10820 | 4.82 | UC3095 | 12 | / | ||
| Model | accelerator | Voltage | Pulling Force | Torque | Current | speed | Power | Efficiency | Motor temperature |
| BGS-UA90 KV220 UC3095L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.40 | 2.20 | 1163 | 48.84 | 20.48 | 50 | ||
| 24.00 | 2000 | 0.85 | 6.67 | 1667 | 148.07 | 13.51 | |||
| 24.00 | 3000 | 1.24 | 11.96 | 2039 | 265.51 | 11.30 | |||
| 180S38℃ | 24.00 | 4000 | 1.12 | 17.87 | 3397 | 396.71 | 10.08 | ||
| 24.00 | 5000 | 2.12 | 25.70 | 2574 | 570.54 | 8.76 | |||
| 24.00 | 6000 | 2.65 | 35.01 | 2800 | 777.22 | 7.72 | |||
| 24.00 | 7000 | 3.24 | 46.40 | 3040 | 1030.08 | 6.80 | |||
| 24.00 | 8000 | 3.68 | 55.80 | 3212 | 1238.76 | 6.46 | |||
| 100% 油门 | 24.00 | 8700 | 3.85 | 61.00 | 3360 | 1354.20 | 6.42 | ||
| BGS-UA90 KV220 UC2995L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.42 | 2.46 | 1229 | 54.61 | 18.31 | 55 | ||
| 24.00 | 2000 | 0.79 | 6.45 | 1727 | 143.19 | 13.97 | |||
| 24.00 | 3000 | 1.20 | 12.02 | 2118 | 266.84 | 11.24 | |||
| 180S37℃ | 24.00 | 4000 | 1.61 | 18.45 | 2434 | 409.59 | 9.77 | ||
| 24.00 | 5000 | 2.10 | 26.68 | 2688 | 592.30 | 8.44 | |||
| 24.00 | 6000 | 2.57 | 35.56 | 2936 | 789.43 | 7.60 | |||
| 24.00 | 7000 | 3.09 | 46.20 | 3171 | 1025.64 | 6.83 | |||
| 100% 油门 | 24.00 | 8300 | 3.69 | 59.80 | 3439 | 1327.56 | 6.25 | ||
| BGS-UA90 KV220 UC2880L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.45 | 2.61 | 1229 | 57.94 | 17.26 | 60 | ||
| 24.00 | 2000 | 0.83 | 6.75 | 1727 | 149.85 | 13.35 | |||
| 24.00 | 3000 | 1.33 | 13.29 | 2118 | 295.04 | 10.17 | |||
| 180S39℃ | 24.00 | 4000 | 1.74 | 20.01 | 2434 | 444.22 | 9.00 | ||
| 24.00 | 5000 | 2.24 | 28.40 | 2688 | 630.48 | 7.93 | |||
| 24.00 | 6000 | 2.77 | 38.36 | 2936 | 851.59 | 7.05 | |||
| 24.00 | 7000 | 3.32 | 49.70 | 3171 | 1103.34 | 6.34 | |||
| 100% 油门 | 24.00 | 8000 | 3.69 | 59.90 | 3439 | 1329.78 | 6.02 | ||
| BGS-UA90 KV150 UC2788L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.35 | 1.24 | 1490 | 55.06 | 18.16 | 60 | ||
| 24.00 | 2000 | 0.72 | 3.50 | 2070 | 155.40 | 12.87 | |||
| 24.00 | 3000 | 1.07 | 6.40 | 2540 | 284.16 | 10.56 | |||
| 24.00 | 4000 | 1.44 | 9.90 | 2920 | 439.56 | 9.10 | |||
| 180S46℃ | 24.00 | 5000 | 1.89 | 14.50 | 3250 | 643.80 | 7.77 | ||
| 24.00 | 6000 | 2.25 | 18.80 | 3550 | 834.72 | 7.19 | |||
| 24.00 | 7000 | 2.57 | 23.10 | 3810 | 1025.64 | 6.83 | |||
| 24.00 | 8000 | 3.11 | 30.00 | 4090 | 1332.00 | 6.01 | |||
| 24.00 | 9000 | 3.63 | 37.00 | 4320 | 1642.80 | 5.48 | |||
| 24.00 | 10000 | 4.28 | 45.80 | 4540 | 2033.52 | 4.92 | |||
| 100% 油门 | 24.00 | 11600 | 5.60 | 63.80 | 4830 | 2832.72 | 4.10 | ||
| BGS-UA90 KV150 UC2480L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.36 | 1.50 | 1770 | 66.60 | 15.02 | 65 | ||
| 24.00 | 2000 | 0.71 | 4.20 | 2500 | 186.48 | 10.73 | |||
| 24.00 | 3000 | 1.06 | 7.50 | 3000 | 333.00 | 9.01 | |||
| 24.00 | 4000 | 1.34 | 10.80 | 3420 | 479.52 | 8.34 | |||
| 24.00 | 5000 | 1.69 | 15.00 | 3770 | 666.00 | 7.51 | |||
| 24.00 | 6000 | 2.09 | 20.50 | 4150 | 910.20 | 6.59 | |||
| 24.00 | 7000 | 2.54 | 26.80 | 4470 | 1189.92 | 5.88 | |||
| 24.00 | 8000 | 3.00 | 33.80 | 4780 | 1500.72 | 5.33 | |||
| 24.00 | 9000 | 3.50 | 41.50 | 5030 | 1842.60 | 4.88 | |||
| 100% 油门 | 24.00 | 10000 | 3.98 | 49.50 | 5280 | 2197.80 | 4.55 | ||
| BGS-UA90 KV120 UC2880L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.39 | 1.14 | 1232 | 50.62 | 19.76 | 65 | ||
| 24.00 | 2000 | 0.74 | 3.06 | 1751 | 135.86 | 14.72 | |||
| 24.00 | 3000 | 1.12 | 5.57 | 2112 | 247.31 | 12.13 | |||
| 24.00 | 4000 | 1.51 | 8.62 | 2421 | 382.73 | 10.45 | |||
| 24.00 | 5000 | 1.94 | 12.44 | 2716 | 552.34 | 9.05 | |||
| 24.00 | 6000 | 2.41 | 16.86 | 2971 | 748.58 | 8.02 | |||
| 24.00 | 7000 | 2.86 | 21.47 | 3187 | 953.27 | 7.34 | |||
| 24.00 | 8000 | 3.43 | 27.80 | 3440 | 1234.32 | 6.48 | |||
| 24.00 | 9000 | 3.95 | 33.50 | 3600 | 1487.40 | 6.05 | |||
| 100% 油门 | 24.00 | 10680 | 5.13 | 46.90 | 3880 | 2082.36 | 5.13 | ||
| BGS-UA90 KV120 UC2995L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.34 | 1.00 | 1240 | 44.40 | 22.52 | 68 | ||
| 24.00 | 2000 | 0.73 | 3.00 | 1740 | 133.20 | 15.02 | |||
| 24.00 | 3000 | 1.08 | 5.50 | 2150 | 244.20 | 12.29 | |||
| 24.00 | 4000 | 1.50 | 8.60 | 2430 | 381.84 | 10.48 | |||
| 180S42℃ | 24.00 | 5000 | 1.82 | 11.50 | 2680 | 510.60 | 9.79 | ||
| 24.00 | 6000 | 2.21 | 15.50 | 2980 | 688.20 | 8.72 | |||
| 24.00 | 7000 | 2.73 | 20.60 | 3200 | 914.64 | 7.65 | |||
| 24.00 | 8000 | 3.14 | 25.20 | 3400 | 1118.88 | 7.15 | |||
| 24.00 | 9000 | 3.83 | 32.50 | 3600 | 1443.00 | 6.24 | |||
| 100% 油门 | 24.00 | 10750 | 4.84 | 44.50 | 3900 | 1975.80 | 5.44 | ||
| BGS-UA90 KV120 UC3095L | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 24.00 | 1000 | 0.39 | 1.10 | 1200 | 48.84 | 20.48 | 68 | ||
| 24.00 | 2000 | 0.69 | 2.70 | 1650 | 119.88 | 16.68 | |||
| 24.00 | 3000 | 1.07 | 5.10 | 2030 | 226.44 | 13.25 | |||
| 24.00 | 4000 | 1.50 | 8.20 | 2320 | 364.08 | 10.99 | |||
| 180S42℃ | 24.00 | 5000 | 2.02 | 12.30 | 2580 | 546.12 | 9.16 | ||
| 24.00 | 6000 | 2.35 | 15.60 | 2810 | 692.64 | 8.66 | |||
| 24.00 | 7000 | 2.83 | 20.20 | 3030 | 896.88 | 7.80 | |||
| 24.00 | 8000 | 3.35 | 25.50 | 3230 | 1132.20 | 7.07 | |||
| 24.00 | 9000 | 3.79 | 30.50 | 3410 | 1354.20 | 6.65 | |||
| 24.00 | 10000 | 4.58 | 38.60 | 3570 | 1713.84 | 5.83 | |||
| 100% 油门 | 24.00 | 11000 | 5.50 | 49.50 | 3815 | 2197.80 | 5.01 | ||
| BGS-UA90 KV120 UC3095 | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 50% | 24.00 | 3990 | 1.54 | 7.95 | 2282 | 367.29 | 10.86 | 70 | |
| 60% | 24.00 | 5350 | 2.29 | 13.82 | 2661 | 638.48 | 8.38 | ||
| 70% | 24.00 | 6890 | 3.05 | 20.86 | 3013 | 963.73 | 7.15 | ||
| 80% | 24.00 | 8520 | 3.96 | 29.75 | 3316 | 1374.45 | 6.20 | ||
| 90% | 24.00 | 9980 | 4.94 | 39.63 | 3540 | 1830.91 | 5.45 | ||
| 100% 油门 | 24.00 | 10820 | 5.86 | 48.55 | 3655 | 2243.01 | 4.82 |
