86.5*29mm
36N48P
200℃
10mm
229g
＞1000h
| MODEL | KV Value | maximum power | Maximum current | pull | Efficiency | Propeller | Battery | ESC | |
| BGS-UA80 | KV | W | A | g | g/W | / | S | A | |
| 100 | 1019.74 | 22.27 | 6434 | 6..31 | UP2910 29inch Folding paddle | 12 | 40 | ||
| 100 | 933.76 | 20.41 | 6397 | 6.85 | UC3095 30inch Straight blade | 12 | 40 | ||
| 140 | 1253.34 | 27.30 | 7044 | 5.62 | UC2480 24inch Straight blade | 12 | 40 | ||
| 170 | 639.05 | 28.09 | 5183 | 8.11 | UC3080 30inch Straight blade | 6 | 60 | ||
| 170 | 677.74 | 29.83 | 5259 | 7.76 | UP2910 29inch Folding paddle | 6 | 60 | ||
| 190 | 856.40 | 37.81 | 5608 | 6.55 | UP2910 29inch Folding paddle | 6 | 60 | ||
| Model | accelerator | Voltage | Pulling Force | Torque | Current | speed | Power | Efficiency | Motor temperature |
| BGS-UA80 KV100 UP2910 29inch Folding paddle | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 46.12 | 1632 | 0.54 | 2.31 | 1417 | 106.54 | 15.32 | 55 | |
| 45% | 46.09 | 2025 | 0.66 | 2.96 | 1549 | 136.43 | 14.84 | ||
| 50% | 46.07 | 2371 | 0.79 | 3.92 | 1703 | 180.59 | 13.13 | ||
| 55% | 46.03 | 2774 | 0.92 | 4.92 | 1836 | 226.47 | 12.25 | ||
| 60% | 46.03 | 3140 | 1.05 | 6.05 | 1952 | 278.48 | 11.28 | ||
| 65% | 45.73 | 3513 | 1.15 | 7.11 | 2067 | 325.14 | 10.80 | ||
| 70% | 45.85 | 3901 | 1.28 | 8.39 | 2173 | 384.68 | 10.14 | ||
| 75% | 45.86 | 4350 | 1.44 | 10.03 | 2295 | 459.98 | 9.46 | ||
| 80% | 45.87 | 4728 | 1.56 | 11.79 | 2420 | 540.81 | 8.74 | ||
| 85% | 45.86 | 5268 | 1.72 | 13.89 | 2528 | 637.00 | 8.27 | ||
| 90% | 45.82 | 5616 | 1.85 | 16.21 | 2637 | 742.74 | 7.56 | ||
| 95% | 45.81 | 5880 | 1.97 | 18.68 | 2751 | 855.73 | 6.87 | ||
| 100% | 45.79 | 6434 | 2.13 | 22.27 | 2816 | 1019.74 | 6.31 | ||
| BGS-UA80 KV100 UC3095 30inch Straight blade | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 46.12 | 1622 | 0.52 | 2.15 | 1426 | 99.16 | 16.36 | 60 | |
| 45% | 46.06 | 1968 | 0.62 | 2.79 | 1571 | 128.51 | 15.31 | ||
| 50% | 46.06 | 2366 | 0.74 | 3.70 | 1726 | 170.42 | 13.88 | ||
| 55% | 46.02 | 2755 | 0.86 | 4.67 | 1864 | 214.91 | 12.82 | ||
| 60% | 45.99 | 3159 | 0.98 | 5.64 | 1985 | 259.38 | 12.18 | ||
| 65% | 45.91 | 3481 | 1.09 | 6.77 | 2109 | 310.81 | 11.20 | ||
| 70% | 45.98 | 3826 | 1.20 | 7.86 | 2219 | 361.40 | 10.59 | ||
| 75% | 45.95 | 4204 | 1.33 | 9.38 | 2347 | 431.01 | 9.75 | ||
| 80% | 45.95 | 4704 | 1.48 | 11.07 | 2465 | 508.67 | 9.25 | ||
| 85% | 45.87 | 5084 | 1.61 | 12.97 | 2593 | 594.93 | 8.55 | ||
| 90% | 45.77 | 5524 | 1.76 | 15.22 | 2697 | 696.62 | 7.93 | ||
| 95% | 45.69 | 5787 | 1.88 | 17.33 | 2806 | 791.81 | 7.31 | ||
| 100% | 45.75 | 6397 | 2.05 | 20.41 | 2908 | 933.76 | 6.85 | ||
| BGS-UA80 KV170 UC3080 30inch Straight blade | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 23.09 | 1313 | 0.42 | 3.24 | 1288 | 74.81 | 17.55 | 65 | |
| 45% | 23.05 | 1629 | 0.51 | 4.35 | 1436 | 100.27 | 16.25 | ||
| 50% | 23.06 | 1930 | 0.61 | 5.68 | 1583 | 130.98 | 14.73 | ||
| 55% | 22.99 | 2250 | 0.70 | 6.88 | 1711 | 158.17 | 14.23 | ||
| 60% | 23.01 | 2607 | 0.80 | 8.56 | 1816 | 196.97 | 13.24 | ||
| 65% | 22.98 | 2909 | 0.91 | 10.33 | 1916 | 237.38 | 12.25 | ||
| 70% | 22.97 | 3250 | 1.01 | 12.21 | 2026 | 280.46 | 11.59 | ||
| 75% | 22.93 | 3550 | 1.10 | 14.19 | 2139 | 325.38 | 10.91 | ||
| 80% | 22.91 | 3843 | 1.21 | 16.44 | 2239 | 376.64 | 10.20 | ||
| 85% | 22.87 | 4170 | 1.32 | 19.13 | 2340 | 437.50 | 9.53 | ||
| 90% | 22.85 | 4544 | 1.43 | 21.87 | 2434 | 499.73 | 9.09 | ||
| 95% | 22.79 | 4909 | 1.55 | 24.98 | 2517 | 569.29 | 8.62 | ||
| 100% | 22.75 | 5183 | 1.65 | 28.09 | 2615 | 639.05 | 8.11 | ||
| BGS-UA80 KV170 UP2910 29inch Folding paddle | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 23.07 | 1382 | 0.45 | 3.33 | 1273 | 76.82 | 17.99 | 70 | |
| 45% | 23.03 | 1742 | 0.55 | 4.41 | 1412 | 101.56 | 17.15 | ||
| 50% | 23.03 | 2033 | 0.67 | 5.97 | 1552 | 137.49 | 14.79 | ||
| 55% | 23.02 | 2352 | 0.76 | 7.46 | 1678 | 171.73 | 13.70 | ||
| 60% | 23.02 | 2698 | 0.86 | 9.07 | 1782 | 208.79 | 12.92 | ||
| 65% | 22.95 | 2922 | 0.96 | 10.81 | 1883 | 248.09 | 11.78 | ||
| 70% | 22.96 | 3287 | 1.08 | 12.95 | 1983 | 297.33 | 11.05 | ||
| 75% | 22.93 | 3626 | 1.20 | 15.32 | 2082 | 351.29 | 10.32 | ||
| 80% | 22.91 | 3965 | 1.29 | 17.52 | 2179 | 401.38 | 9.88 | ||
| 85% | 22.87 | 4334 | 1.42 | 20.51 | 2272 | 469.06 | 9.24 | ||
| 90% | 22.82 | 4599 | 1.52 | 23.12 | 2378 | 527.60 | 8.72 | ||
| 95% | 22.79 | 4944 | 1.63 | 26.51 | 2458 | 604.16 | 8.18 | ||
| 100% | 22.72 | 5259 | 1.75 | 29.83 | 2533 | 677.74 | 7.76 | ||
| BGS-UA80 KV190 UP2910 29inch Folding paddle | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 23.04 | 1586 | 0.52 | 4.35 | 1369 | 100.22 | 15.82 | 75 | |
| 45% | 23.04 | 1955 | 0.64 | 5.89 | 1517 | 135.71 | 14.41 | ||
| 50% | 23.01 | 2326 | 0.76 | 7.71 | 1659 | 177.41 | 13.11 | ||
| 55% | 22.98 | 2655 | 0.86 | 9.56 | 1779 | 219.69 | 12.09 | ||
| 60% | 22.96 | 2939 | 0.96 | 11.43 | 1898 | 262.43 | 11.20 | ||
| 65% | 22.94 | 3255 | 1.07 | 13.68 | 2004 | 313.82 | 10.37 | ||
| 70% | 22.92 | 3560 | 1.18 | 16.23 | 2110 | 371.99 | 9.57 | ||
| 75% | 22.88 | 3926 | 1.29 | 18.94 | 2202 | 433.35 | 9.06 | ||
| 80% | 22.85 | 4289 | 1.42 | 22.03 | 2303 | 503.39 | 8.52 | ||
| 85% | 22.81 | 4666 | 1.55 | 25.64 | 2387 | 584.85 | 7.98 | ||
| 90% | 22.75 | 4960 | 1.65 | 29.12 | 2477 | 662.48 | 7.49 | ||
| 95% | 22.68 | 5339 | 1.79 | 33.35 | 2548 | 756.38 | 7.06 | ||
| 100% | 22.65 | 5608 | 1.90 | 37.81 | 2615 | 856.40 | 6.55 |
