69.5*39.5mm
24N22P
200℃
IN: 8mm
445.1±12g
>1000h
| Item | Specification |
| Model:F6218 | Enameled Wire Grade:Class H (180℃ High Temperature Resistant) |
| Rated KV:200KV | Service Life:≥1000 Hours |
| Motor Dimension:Outer Dia 69.5mm × Thickness 39.5mm | Outer Dia 69.5mm × Thickness 39.5mm |
| Shaft Diameter:8mm | Max Static Thrust:20kg (6S LiPo, matched 17-inch propeller) |
| Net Weight (with wire):445.1±12g | Applicable Battery:6S LiPo Battery |
| Stator Slot Structure:12 Slots | Matched Propeller:17-inch Heavy Load Propeller |
| MODEL | KV Value | Maximum power | Maximum current | Pull | Efficiency | Propeller | Battery | ESC | |
| BGS-F6218 | KV | W | A | g | g/W | / | S | A | |
| 200 | 998 | 51.8 | 10400 | 10.42 | / | 24 | 80 | ||
| Model | Throttle | Voltage | Current | Input Power | Speed | Thrust | Power Efficiency |
| % | V | A | W | RPM | gf | gf/W | |
| TORHANG F6218 200KV | 30 | 25.11 | 9.75 | 244.8 | 3810 | 989 | 4.04 |
| 35 | 25.07 | 13.03 | 326.7 | 4505 | 1395 | 4.27 | |
| 40 | 25.03 | 18.56 | 464.6 | 5145 | 1659 | 3.57 | |
| 45 | 24.98 | 23.55 | 588.3 | 5765 | 1947 | 3.31 | |
| 50 | 24.94 | 32.54 | 811.5 | 6380 | 2451 | 3.02 | |
| 55 | 24.89 | 38.52 | 958.8 | 6970 | 2943 | 3.07 | |
| 60 | 24.84 | 50.58 | 1256.4 | 7535 | 3455 | 2.75 | |
| 65 | 24.79 | 57.97 | 1437.1 | 8070 | 3981 | 2.77 | |
| 70 | 24.74 | 66.72 | 1650.7 | 8580 | 4490 | 2.72 | |
| 75 | 24.69 | 72.7 | 1795 | 9055 | 4972 | 2.77 | |
| 80 | 24.64 | 85.04 | 2095.4 | 9495 | 5511 | 2.63 | |
| 85 | 24.59 | 98.86 | 2431 | 9895 | 6078 | 2.5 | |
| 90 | 24.54 | 115.85 | 2842.9 | 10250 | 6595 | 2.32 | |
| 95 | 24.48 | 127.89 | 3130.7 | 10555 | 7075 | 2.26 | |
| 100 | 24.43 | 140.52 | 3432.9 | 10804 | 20015 | 5.83 |
Application Scenarios
-Large-capacity agricultural pesticide spraying drone
-Heavy cargo delivery logistics UAV
-Industrial aerial hoisting & lifting drone
-Long-endurance large-scale mapping & surveying UAV
-Custom multi-rotor heavy-lift industrial drone
1.Propeller: 17-inch heavy-load carbon fiber propeller
2.ESC: 200A+ high-current heavy-duty brushless ESC
3.Battery: 6S lithium polymer battery
4.Frame: 65-inch / 70-inch large multi-rotor UAV frame
1.Ultra High Thrust & Large Torque: Max 20kg single-motor thrust, perfectly meets heavy-lift UAV takeoff demand
2.High Temperature Resistant Winding: Class H high-temperature enameled wire, anti-overheat under long continuous heavy-load work
3.Solid Mechanical Structure: 8mm thickened main shaft, anti-vibration & anti-deformation under high-speed rotation
4.Stable Consistency: Strict dynamic balance calibration, low vibration, low noise, long service lifespan
5.Wide Application Compatibility: Matches mainstream heavy-duty ESC, convenient assembly and replacement
