27.7*25mm
12N14P
200℃
M6
50g
＞1000h
| Model | KV Value | Maximum Power | Maximum Current | Pull | Efficiency | Propeller | Battery Lipo Cells | ESC | |
| BGS-F2212 | KV | W | A | g | g/W | / | S | A | |
| 920 | 81 | 7.3 | 465 | 5.7 | 8045 | 3S | 20 | ||
| 920 | 105 | 9.5 | 642 | 6.1 | 1045 | 3S | 20 | ||
| 980 | 90 | 8.1 | 535 | 5.9 | 8045 | 3S | 20 | ||
| Model | Voltage | Propeller | Accelerator | Current | Power | Thrust | Speed | Efficiency | Motor temperature |
| BGS-F2212 920KV | V | / | % | A | W | g | rpm | g/W | ℃ |
| 14.8 | T-MOTOR 9545B | 50% | 2.1 | 31.08 | 293 | 4260 | 9.43 | / | |
| 14.8 | 65% | 4 | 59.2 | 476 | 5300 | 8.04 | / | ||
| 14.8 | 75% | 5.6 | 82.88 | 605 | 5960 | 7.3 | / | ||
| 14.8 | 85% | 7.4 | 109.52 | 742 | 6000 | 6.78 | / | ||
| 14.8 | 100% | 10.3 | 152.44 | 918 | 7350 | 6.02 | / | ||
| BGS-F2212 980KV | 11.1 | 50% | 1.6 | 17.76 | 176 | 4400 | 9.91 | / | |
| 11.1 | 65% | 3 | 33.3 | 289 | 5500 | 8.68 | / | ||
| 11.1 | 75% | 4.3 | 47.73 | 385 | 6400 | 8.07 | / | ||
| 11.1 | 85% | 5.8 | 64.38 | 475 | 7000 | 7.38 | / | ||
| 11.1 | 100% | 8.1 | 89.91 | 617 | 7800 | 6.86 | / |
The 2212 motor is widely used in 5"–6" micro FPV racing drones, offering pilots strong acceleration, fast throttle response, and precise control for tight courses and indoor tracks.
Features:
-Quick response for rapid maneuvers
-Smooth power delivery at mid-throttle
-Stable performance for lightweight builds
For indoor freestyle flying, where space is constrained, the 1106 provides excellent agility and minimal inertia, allowing pilots to perform rapid flips, rolls, and transitions with precision.
When equipped in ultra-light micro cinematic drones carrying small cameras, the 1106 motor ensures smooth and consistent RPM, minimizing vibrations and producing stable footage in compact setups.
The 1106 is also suitable for nano drones or “toothpick” frames (typically 65–90 mm wheelbase), where light weight and efficiency are critical.
1.High RPM Output– Allows micro propellers to spin at high speed for agile flight.
2.Rapid Throttle Response – Low rotor inertia ensures instantaneous response to pilot input.
3.Efficient Micro Power Delivery – Optimized for small propellers and low-voltage setups to minimize heat generation.
