92*40mm
36N40P
200℃
15 mm
688g
＞1000h
| Model | KV Value | Maximum Power | Maximum Current | Pull | Efficiency | Awe | Battery | ESC | |
| BG-H95 | KV | W | A | g | g/W | / | S | A | |
| 100 | 2531.09 | 49.6 | 13126 | 5.19 | 28"straight oar | 14S | 80 | ||
| 120 | 2511.55 | 57.75 | 12893 | 5.13 | 28"straight oar | 12S | 80 | ||
| 120 | 2696.26 | 62.04 | 14093 | 5.23 | 30"straight oar | 12S | 80 | ||
| Model | Accelerator | Voltage | Pulling Force | Torque | Current | Speed | Power | Efficiency | Motor Temperature |
| BG-H95 KV100 | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 45% | 51.52 | 3458 | 1.35 | 6.18 | 2252 | 318.39 | 10.86 | 76 | |
| 50% | 51.53 | 4154 | 1.63 | 8.21 | 2486 | 423.06 | 9.82 | ||
| 60% | 51.46 | 5677 | 2.19 | 12.85 | 2881 | 661.26 | 8.59 | ||
| 70% | 51.37 | 7408 | 2.85 | 19.14 | 3293 | 983.22 | 7.53 | ||
| 80% | 51.3 | 9215 | 3.65 | 27.45 | 3687 | 1408.19 | 6.54 | ||
| 85% | 51.22 | 10218 | 4.08 | 32.35 | 3883 | 1656.97 | 6.17 | ||
| 90% | 51.15 | 11025 | 4.46 | 37.09 | 4062 | 1897.15 | 5.81 | ||
| 95% | 51.12 | 11755 | 4.9 | 42.43 | 4229 | 2169.02 | 5.42 | ||
| 100% | 51.03 | 13126 | 5.54 | 49.6 | 4364 | 2531.09 | 5.19 |
