54*12mm
24N28P
200℃
6mm
245g
＞1000h
| Model | KV Value | Maximum Power | Maximum Current | Pull | Efficiency | Awe | Battery | ESC | |
| BG-H5412 | KV | W | A | g | g/W | / | S | A | |
| 190 | 921.31 | 20.46 | 4960 | 5.3836 | 18"straight oar | 12S | 80 | ||
| 280 | 786.61 | 36.35 | 4080 | 5.1868 | 22"straight oar | 6S | 80 | ||
| 340 | 836.26 | 38.68 | 4236 | 5.0654 | 20"straight oar | 6S | 80 | ||
| Model | Accelerator | Voltage | Pulling Force | Torque | Current | Speed | Power | Efficiency | Motor Temperature |
| BG-H5412 KV190 | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 45% | 45.47 | 1268 | 0.3103 | 2.57 | 3597 | 116.86 | 10.8508 | 56 | |
| 50% | 45.46 | 1515 | 0.367 | 3.32 | 3927 | 150.93 | 10.038 | ||
| 60% | 45.43 | 2074 | 0.4775 | 5.04 | 4579 | 228.97 | 9.0581 | ||
| 70% | 45.33 | 2730 | 0.6106 | 7.42 | 5261 | 336.35 | 8.1166 | ||
| 80% | 45.26 | 3399 | 0.7799 | 10.6 | 5875 | 479.76 | 7.0849 | ||
| 85% | 45.22 | 3720 | 0.8799 | 12.63 | 6199 | 571.13 | 6.5134 | ||
| 90% | 45.17 | 4191 | 1.0026 | 15.13 | 6510 | 683.42 | 6.1324 | ||
| 95% | 45.08 | 4402 | 1.0712 | 16.92 | 6800 | 762.75 | 5.7712 | ||
| 100% | 45.03 | 4960 | 1.2426 | 20.46 | 7081 | 921.31 | 5.3836 |
