147.6*61mm
36N42P
200℃
31mm
1592g
＞1000h
| MODEL | KV Value | maximum power | Maximum current | pull | Efficiency | Propeller | Battery | ESC | |
| BGS-UA150 | KV | W | A | g | g/W | / | S | A | |
| 40 | 7806.72 | 85.60 | 38322 | 4.91 | UF52 52inch Straight blade | 24 | 120 | ||
| 66 | 9247.68 | 136.80 | 38307 | 4.14 | UP43135 43inch Folding paddle | 18 | 180 | ||
| 75 | 9247.68 | 136.80 | 38307 | 4.14 | UF52 52inch Straight blade | 14 | 200 | ||
| 88 | 8270.76 | 188.40 | 37669 | 4.55 | UF52 52inch Straight blade | 12 | 200 | ||
| 88 | 8240.76 | 188.40 | 34671 | 4.19 | UP48190 48inch Folding paddle | 12 | 200 | ||
| 100 | 9192.75 | 178.50 | 38577 | 4.20 | UF4295 42inch Straight blade | 14 | 200 | ||
| Model | accelerator | Voltage | Pulling Force | Torque | Current | speed | Power | Efficiency | Motor temperature |
| BGS-UA150 KV40 UF52 52inch Straight blade | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 92.00 | 8599 | 4.90 | 8.50 | 1264 | 782.00 | 11.00 | 50 | |
| 45% | 92.00 | 10423 | 5.80 | 10.90 | 1379 | 1002.80 | 10.39 | ||
| 50% | 92.00 | 12391 | 6.90 | 13.80 | 1487 | 1269.60 | 9.76 | ||
| 55% | 91.90 | 14607 | 8.00 | 17.40 | 1617 | 1599.06 | 9.13 | ||
| 60% | 91.90 | 16766 | 9.40 | 22.00 | 1749 | 2021.80 | 8.29 | ||
| 65% | 91.80 | 19114 | 10.90 | 27.20 | 1866 | 2496.96 | 7.65 | ||
| 70% | 91.70 | 21655 | 12.20 | 32.80 | 1982 | 3007.76 | 7.20 | ||
| 75% | 91.70 | 24317 | 13.40 | 38.10 | 2089 | 3493.77 | 6.96 | ||
| 80% | 91.60 | 27054 | 15.10 | 46.00 | 2206 | 4213.60 | 6.42 | ||
| 85% | 91.50 | 30240 | 16.90 | 55.40 | 2314 | 5069.10 | 5.97 | ||
| 90% | 91.40 | 33058 | 18.30 | 64.30 | 2425 | 5877.02 | 5.62 | ||
| 95% | 91.30 | 35789 | 19.80 | 74.80 | 2510 | 6829.24 | 5.24 | ||
| 100% | 91.20 | 38322 | 20.60 | 85.60 | 2688 | 7806.72 | 4.91 | ||
| BGS-UA150 KV66 UP43135 43inch Folding paddle | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 69.00 | 8655 | 4.20 | 13.50 | 1618 | 931.50 | 9.29 | 55 | |
| 45% | 69.00 | 10875 | 5.30 | 18.40 | 1818 | 1269.60 | 8.57 | ||
| 50% | 68.90 | 13437 | 6.70 | 24.90 | 2006 | 1715.61 | 7.83 | ||
| 55% | 68.80 | 15833 | 7.90 | 31.70 | 2172 | 2180.96 | 7.26 | ||
| 60% | 68.80 | 18185 | 9.10 | 39.30 | 2334 | 2703.84 | 6.73 | ||
| 65% | 68.60 | 21039 | 10.60 | 48.70 | 2486 | 3340.82 | 6.30 | ||
| 70% | 68.60 | 23345 | 11.70 | 57.00 | 2618 | 3910.20 | 5.97 | ||
| 75% | 68.40 | 26007 | 13.20 | 68.30 | 2770 | 4671.72 | 5.57 | ||
| 80% | 68.30 | 29222 | 14.80 | 81.80 | 2914 | 5586.94 | 5.23 | ||
| 85% | 68.10 | 32157 | 16.30 | 96.60 | 3051 | 6578.46 | 4.89 | ||
| 90% | 67.90 | 34756 | 17.70 | 112.10 | 3185 | 7611.59 | 4.57 | ||
| 95% | 67.60 | 38201 | 19.40 | 136.10 | 3336 | 9200.36 | 4.15 | ||
| 100% | 67.60 | 38307 | 19.20 | 136.80 | 3346 | 9247.68 | 4.14 | ||
| BGS-UA150 KV75 UF52 52inch Straight blade | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 69.00 | 8655 | 4.20 | 13.50 | 1618 | 931.50 | 9.29 | 60 | |
| 45% | 69.00 | 10875 | 5.30 | 18.40 | 1818 | 1269.60 | 8.57 | ||
| 50% | 68.90 | 13437 | 6.70 | 24.90 | 2006 | 1715.61 | 7.83 | ||
| 55% | 68.80 | 15833 | 7.90 | 31.70 | 2172 | 2180.96 | 7.26 | ||
| 60% | 68.80 | 18185 | 9.10 | 39.30 | 2334 | 2703.84 | 6.73 | ||
| 65% | 68.60 | 21039 | 10.60 | 48.70 | 2486 | 3340.82 | 6.30 | ||
| 70% | 68.60 | 23345 | 11.70 | 57.00 | 2618 | 3910.20 | 5.97 | ||
| 75% | 68.40 | 26007 | 13.20 | 68.30 | 2770 | 4671.72 | 5.57 | ||
| 80% | 68.30 | 29222 | 14.80 | 81.80 | 2914 | 5586.94 | 5.23 | ||
| 85% | 68.10 | 32157 | 16.30 | 96.60 | 3051 | 6578.46 | 4.89 | ||
| 90% | 67.90 | 34756 | 17.70 | 112.10 | 3185 | 7611.59 | 4.57 | ||
| 95% | 67.60 | 38201 | 19.40 | 136.10 | 3336 | 9200.36 | 4.15 | ||
| 100% | 67.60 | 38307 | 19.20 | 136.80 | 3346 | 9247.68 | 4.14 | ||
| BGS-UA150 KV88 UF52 52inch Straight blade | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 45.90 | 9679 | 5.10 | 19.60 | 1315 | 899.64 | 10.76 | 60 | |
| 45% | 45.80 | 11632 | 6.20 | 25.90 | 1442 | 1186.22 | 9.81 | ||
| 50% | 45.70 | 13616 | 7.20 | 32.70 | 1560 | 1494.39 | 9.11 | ||
| 55% | 45.60 | 16184 | 8.60 | 42.00 | 1688 | 1915.20 | 8.45 | ||
| 60% | 45.50 | 18085 | 9.90 | 52.30 | 1820 | 2379.65 | 7.60 | ||
| 65% | 45.40 | 19830 | 11.30 | 63.80 | 1941 | 2896.52 | 6.85 | ||
| 70% | 45.20 | 23317 | 12.60 | 76.30 | 2054 | 3448.76 | 6.76 | ||
| 75% | 45.00 | 25717 | 14.10 | 91.20 | 2149 | 4104.00 | 6.27 | ||
| 80% | 44.80 | 27796 | 15.50 | 107.10 | 2239 | 4798.08 | 5.79 | ||
| 85% | 44.60 | 30620 | 16.90 | 125.20 | 2320 | 5583.92 | 5.48 | ||
| 90% | 44.40 | 32701 | 18.00 | 142.40 | 2406 | 6322.56 | 5.17 | ||
| 95% | 44.20 | 34503 | 19.00 | 161.60 | 2471 | 7142.72 | 4.83 | ||
| 100% | 43.90 | 37669 | 20.20 | 188.40 | 2536 | 8270.76 | 4.55 | ||
| BGS-UA150 KV88 UP48190 48inch Folding paddle | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 45.90 | 9599 | 5.30 | 19.80 | 1330 | 908.82 | 10.56 | 65 | |
| 45% | 45.80 | 11401 | 6.40 | 26.00 | 1456 | 1190.80 | 9.57 | ||
| 50% | 45.70 | 13408 | 7.50 | 33.10 | 1576 | 1512.67 | 8.86 | ||
| 55% | 45.60 | 15481 | 8.80 | 42.20 | 1707 | 1924.32 | 8.04 | ||
| 60% | 45.50 | 18503 | 10.40 | 53.40 | 1831 | 2429.70 | 7.62 | ||
| 65% | 45.30 | 20702 | 11.80 | 65.20 | 1949 | 2953.56 | 7.01 | ||
| 70% | 45.20 | 23250 | 13.20 | 78.80 | 2055 | 3561.76 | 6.53 | ||
| 75% | 45.00 | 25649 | 14.60 | 92.90 | 2154 | 4180.50 | 6.14 | ||
| 80% | 44.80 | 28118 | 15.90 | 108.70 | 2245 | 4869.76 | 5.77 | ||
| 85% | 44.60 | 30421 | 17.20 | 126.20 | 2328 | 5628.52 | 5.40 | ||
| 90% | 44.40 | 32085 | 18.40 | 144.70 | 2406 | 6424.68 | 4.99 | ||
| 95% | 44.20 | 33501 | 19.40 | 163.90 | 2470 | 7244.38 | 4.62 | ||
| 100% | 43.90 | 34671 | 20.30 | 188.40 | 2542 | 8270.76 | 4.19 | ||
| BGS-UA150 KV100 UF4295 42inch Straight blade | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 53.40 | 7830 | 3.20 | 16.60 | 1874 | 886.44 | 8.83 | 65 | |
| 45% | 53.30 | 10074 | 4.10 | 23.10 | 2108 | 1231.23 | 8.18 | ||
| 50% | 53.20 | 12527 | 5.30 | 31.30 | 2334 | 1665.16 | 7.52 | ||
| 55% | 53.10 | 14615 | 6.20 | 39.30 | 2531 | 2086.83 | 7.00 | ||
| 60% | 53.00 | 17145 | 7.30 | 49.10 | 2716 | 2602.30 | 6.59 | ||
| 65% | 52.90 | 19271 | 8.30 | 59.30 | 2885 | 3136.97 | 6.14 | ||
| 70% | 52.80 | 21554 | 9.40 | 70.60 | 3041 | 3727.68 | 5.78 | ||
| 75% | 52.60 | 24032 | 10.50 | 83.00 | 3207 | 4365.80 | 5.50 | ||
| 80% | 52.50 | 26726 | 11.70 | 98.00 | 3363 | 5145.00 | 5.19 | ||
| 85% | 52.30 | 29585 | 13.00 | 114.70 | 3522 | 5998.81 | 4.93 | ||
| 90% | 52.00 | 32164 | 14.20 | 132.40 | 3673 | 6884.80 | 4.67 | ||
| 95% | 51.80 | 35305 | 15.50 | 152.70 | 3805 | 7909.86 | 4.46 | ||
| 100% | 51.50 | 38577 | 17.00 | 178.50 | 3958 | 9192.75 | 4.20 |
