| MODEL | KV Value | maximum power | Maximum current | pull | Efficiency | Propeller | Battery | ESC | |
| BGS-EA240 | KV | W | A | g | g/W | / | S | A | |
| 9 | 58232.78 | 163.30 | 193500 | 3.32 | 76inch Straight blade | 96 | 180 | ||
| 8 | 57755.88 | 159.90 | 200505 | 3.47 | 76inch Straight blade | 96 | 120 | ||
| Model | accelerator | Voltage | Pulling Force | Torque | Current | speed | Power | Efficiency | Motor temperature |
| BGS-EA240 KV9 | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 368.70 | 41973 | 28.30 | 14.30 | 1379 | 5272.41 | 7.96 | 60 | |
| 45% | 368.40 | 52078 | 35.40 | 19.10 | 1522 | 7036.44 | 7.40 | ||
| 50% | 367.80 | 65478 | 44.00 | 25.30 | 1684 | 9305.34 | 7.04 | ||
| 55% | 367.20 | 80654 | 54.40 | 33.90 | 1867 | 12448.08 | 6.48 | ||
| 60% | 367.00 | 97283 | 66.70 | 44.70 | 2042 | 16404.90 | 5.93 | ||
| 65% | 366.10 | 110931 | 76.90 | 54.90 | 2188 | 20098.89 | 5.52 | ||
| 70% | 365.80 | 126317 | 90.90 | 68.80 | 2331 | 25167.04 | 5.02 | ||
| 75% | 365.90 | 140462 | 104.90 | 84.00 | 2471 | 30735.60 | 4.57 | ||
| 80% | 365.10 | 158972 | 124.60 | 105.60 | 2609 | 38554.56 | 4.12 | ||
| 85% | 364.00 | 174280 | 141.60 | 131.50 | 2749 | 47866.00 | 3.64 | ||
| 90% | 362.10 | 181240 | 149.80 | 145.20 | 2815 | 52576.92 | 3.45 | ||
| 95% | 358.80 | 186430 | 152.20 | 152.30 | 2868 | 54645.24 | 3.41 | ||
| 100% | 356.60 | 193500 | 154.10 | 163.30 | 2910 | 58232.78 | 3.32 | ||
| BGS-EA240 KV8 | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 40% | 368.40 | 74727 | 51.50 | 30.20 | 1835 | 11125.68 | 6.72 | 65 | |
| 45% | 368.20 | 88567 | 60.90 | 38.40 | 1978 | 14138.88 | 6.26 | ||
| 50% | 368.20 | 102830 | 69.70 | 46.60 | 2108 | 17158.12 | 5.99 | ||
| 55% | 367.40 | 116645 | 80.80 | 56.10 | 2229 | 20611.14 | 5.66 | ||
| 60% | 366.90 | 129848 | 91.00 | 66.20 | 2338 | 24288.78 | 5.35 | ||
| 65% | 367.00 | 142310 | 103.10 | 78.50 | 2439 | 28809.50 | 4.94 | ||
| 70% | 367.00 | 152972 | 115.00 | 90.40 | 2533 | 33176.80 | 4.61 | ||
| 75% | 366.50 | 163094 | 127.50 | 104.20 | 2620 | 38189.30 | 4.27 | ||
| 80% | 366.00 | 172017 | 139.10 | 117.40 | 2705 | 42968.40 | 4.00 | ||
| 85% | 365.40 | 178887 | 145.00 | 131.30 | 2782 | 47977.02 | 3.73 | ||
| 90% | 364.70 | 181376 | 159.00 | 138.50 | 2810 | 50510.95 | 3.59 | ||
| 95% | 363.20 | 192636 | 162.00 | 151.20 | 2902 | 54915.84 | 3.51 | ||
| 100% | 361.20 | 200505 | 166.00 | 159.90 | 2925 | 57755.88 | 3.47 |
