50*10mm
24N28P
200℃
4mm
195g
＞1000h
| Model | KV Value | Maximum Power | Maximum Current | Pull | Efficiency | Awe | Battery | ESC | |
| BG-H501 | KV | W | A | g | g/W | / | S | A | |
| 200 | 452.8 | 20.78 | 3410 | 7.53 | 24''folding paddle | 6S | 60 | ||
| 310 | 887.95 | 41.59 | 4202 | 4.73 | 21''folding paddle | 6S | 60 | ||
| 360 | 1039.8 | 48.84 | 4676 | 4.5 | 20''folding paddle | 6S | 60 | ||
| Model | Accelerator | Voltage | Pulling Force | Torque | Current | Speed | Power | Efficiency | Motor Temperature |
| BG-P501 KV200 | % | V | g | N.m | A | rpm | W | g/W | ℃ |
| 45% | 21.99 | 1211 | 0.47 | 3.91 | 1763 | 85.98 | 14.08 | 54 | |
| 50% | 22.01 | 1405 | 0.56 | 5.09 | 1926 | 112.03 | 12.54 | ||
| 60% | 21.95 | 1885 | 0.73 | 7.71 | 2206 | 169.23 | 11.14 | ||
| 70% | 21.92 | 2359 | 0.93 | 10.87 | 2449 | 238.27 | 9.9 | ||
| 80% | 21.87 | 2825 | 1.14 | 14.66 | 2678 | 320.61 | 8.81 | ||
| 85% | 21.87 | 2986 | 1.24 | 16.41 | 2766 | 358.89 | 8.32 | ||
| 90% | 21.82 | 3227 | 1.35 | 18.58 | 2861 | 405.42 | 7.96 | ||
| 95% | 21.81 | 3338 | 1.43 | 20.05 | 2920 | 437.29 | 7.63 | ||
| 100% | 21.79 | 3410 | 1.46 | 20.78 | 2955 | 452.8 | 7.53 |
