BGS-F1306 4000KV Micro drone motor

Product Number:F1306

get free solutions compare

Three-phase brushless external rotor motor, 12N14P groove design, focusing on large pulling force, long endurance, low noise, suitable for heavy-duty long-distance cruising, professional film and television aerial photography.

Motor dimensions
17.6*12.7mm
Number of slots
9N12P
Copper wire grade
200℃
Shaft diameter
M5
Motor weight
11g
Service life
＞1000h

Basic Data

Model	KV Value	Maximum Power	Maximum Current	Pull	Efficiency	Propeller	Battery Lipo Cells	ESC
BGS-F1306	KV	W	A	g	g/W	/	S	A
	3100	44	6	180	4.1	4040	2S	15
	3100	53	7.2	210	4	6020	2S	15
	4000	52	7	218	4.2	5030	2S	15
